244 Part Number STH025 11/16
I0850W
Self-Contained Water-Cooled Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.4-9.7 9.5-10.9 10.7-12.3
1-2.5
80/27 8.7-10.1 9.7-11.1 10.8-12.6
90/32 9.1-10.5 11.4-13.1 11.0-12.8
100/38 9.5-10.9 10.3-11.9 11.3-13.0
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 835 755 680
80/27 810 740 665
90/32 780 640 655
100/38 755 700 645
110/43 730 680 635
1 Based on average ice slab weight of 5.75 - 6.50 lb.
OPERATING PRESSURES
Air Temp
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 230-240 45-28 135-160 70-85
70/21 230-240 60-28 135-160 70-85
80/27 230-240 65-28 135-160 70-85
90/32 240-250 65-28 135-160 70-90
100/38 240-255 70-30 140-160 75-95
110/43 240-265 70-32 140-160 75-95
1 Suction pressure drops gradually throughout the freeze cycle
2 Water regulating valve set to maintain 230 psig
3 Condenser Water Usage = 150 gal/100 lb ice @ 90°/70°F
