Manitowoc Indigo ID0502A User Manual

Part Number STH025 11/16 245
I0850N
Remote Air-Cooled Condenser Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to
70/21
95-11.0 11.0-12.6 12.0-13.7
0.75-2.0
80/27 10.0-11.5 10.8-12.4 11.2-12.9
90/32 11.3-13.0 12.1-13.8 13.4-15.4
100/38 12.0-13.7 13.0-14.9 14.1-16.2
110/43 12.8-14.6 13.8-15.8 14.9-17.0
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
-20/-29 to 70/21 750 665 615
80/27 720 675 650
90/32 645 610 555
100/38 615 570 530
110/43 580 540 505
1 Based on average ice slab weight of 5.75 - 6.50 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 200-220 40-21 140-160 70-85
70/21 225-250 50-30 140-160 70-90
80/27 250-265 55-31 140-160 70-95
90/32 260-295 60-32 140-160 70-95
100/38 310-375 65-35 145-170 75-100
110/43 325-390 70-36 145-170 80-100
1 Suction pressure drops gradually throughout the freeze cycle
