Manitowoc IYF0900C Technician's Handbook

Part Number: 000015431 Rev01 5/19 149
Thermistor Matrix
Four thermistors are standard on the ice machine. They
are labeled T1, T2, T3, T4. Three additional thermistors are
available as an option and measure ice bin level, potable
water supply temperature and air temperature entering
the condenser.
TEMPERATURE SENSOR LOCATION
Models with 1 evaporator, 1 evaporator circuit
See page 202 for graphic
T1 - Receiver Inlet
T2 - Receiver Outlet
T3 - Evaporator Inlet
T4 - Evaporator Outlet
Models with 1 evaporator, 2 evaporator circuits
See page 204 for graphic
T1 - Receiver Inlet
T2 - Receiver Outlet
T3 - Evaporator Outlet for second evaporator circuit
T4 - Evaporator Outlet for first evaporator circuit
Models with 2 evaporators, 1 circuit
See page 206 for graphic
T1 - Receiver Inlet
T2 - Receiver Outlet
T3 - Evaporator Outlet for second evaporator circuit
T4 - Evaporator Outlet for first evaporator circuit
Models with 2 evaporators, 2 circuits
See page 208 for graphic
T1 - Receiver Inlet
T2 - Receiver Outlet
T3 - Evaporator Outlet for second evaporator circuit
T4 - Evaporator Outlet for first evaporator circuit
