Manitowoc IYF0900C Technician's Handbook

186 Part Number: 000015431 Rev01 5/19
IF1400C/CVDF1400
Remote Air-Cooled Condensing Unit Model
Characteristics vary depending on operating conditions.
All data on this page is preliminary and subject to change
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
11.3-13.4 12.3-14.6 14.2-16.8
.75-2.590/32 12.8-15.2 13.7-16.3 16.0-18.9
100/38 13.8-16.3 15.8-18.7 17.1-20.2
110/43 14.7-17.4 16.9-19.9 18.2-21.5
1
Times in minutes - Dice cube
24-Hour Ice Production
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
1350 1255 1100
90/32 1210 1135 990
100/38 1130 1000 930
110/43 1065 940 875
1
Ice slab weight of one harvest cycle = 12.0 lb. to 14.0 lb.
6.0 to 7.0 lbs per evaporator
5.44 kg to 6.35 kg (2.72 to 3.18 kg per evaporator)
230/50/1 is approximately 12% lower than 230/60/1.
Operating Pressures
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
250-235 50-36 140-165 70-95
70/21 250-235 55-38 150-170 70-95
80/27 275-240 60-38 160-180 85-95
90/32 300-285 65-39 170-190 90-110
100/38 350-300 70-40 180-200 95-115
110/43 410-350 80-40 190-215 100-125
