National Crane Published 12-21-2012 Control # 103-06 5-5
1400A OPERATOR’S MANUAL LUBRICATION
Internal Cable Sheave Lubrication
A grease gun adapter is required to lubricate the internal
sheaves. The required needle grease gun fitting is:
• A 0.25 inch (6.35 mm) diameter nozzle grease gun tip
(National P/N 955045).
• Contact Manitowoc Crane Care to obtain this tip.
Lubrication of the extend and retract sheaves is as follows:
1. Extend the boom until the grease access holes on the
side of the boom sections are lined up.
2. Lubricate the pin for the extend cable sheaves (18)
(Figure 5-1) until a small amount of grease extrudes
from the pin. From in front of the boom, look back
through the sheave case at the pin to determine the
amount of grease.
3. This position also aligns the access holes in the rear of
the boom for lubrication.
4. Lubricate the pins for the retract sheaves until a small
amount of grease extrudes from the sheave pins. From
in back of the boom, look up through the hoist mount at
the pins to determine the amount of grease.
Boom Lubrication Inner Wear Pad
1. Fully extend and set the outriggers.
2. With the boom fully retracted, remove the access
plate (6) located on the top rear of the 1
ST
section
(Figure 5-2).
3. Apply grease to the wear pads on the top of the 2
ND
section through the access holes (4) in the 1
ST
section
with a grease gun (Figure 5-2).
4. Extend the boom to line up the access holes on the 2
ND
section (3) with the wear pads on the 3
RD
section. Apply
grease to the 3
RD
section wear pads with a grease gun.
5. Extend the boom to line up the access holes (2) on the
3
RD
section with the wear pads on the 4
TH
section. Apply
grease to the 4
TH
section wear pads with a grease gun.
6. Raise the boom to at least 75°.
7. Extend the boom about 1/3 and retract to spread the
grease.
8. Repeat steps 3 - 6. Extend the boom about 2/3 and
retract to spread the grease.
9. Repeat steps 3 - 6. Fully extend and retract the boom to
spread the grease.
Boom Lubrication Side/Bottom Wear Pad
1. Fully extend and set the outriggers.
2. Lower the boom to horizontal.
3. Fully extend the boom and apply grease to the side and
bottom of the 2
ND
,
3
RD
, and 4
TH
sections with a brush.
4. Raise the boom to about 75° and retract the boom.
5. Extend and retract the boom several times until the
grease is evenly spread.
6. Repeat steps 2 - 5 as necessary to ensure the boom is
fully lubricated.
11 Swing drive gearbox AGMA EP-4 Change After 100 operating hours
12 Swing gear teeth EP-OGL Spray Can Monthly
13 Boom Jib EP-MPG Brush, roller, or grease gun Monthly or as required
14 Outrigger beams, bottom, sides EP-MPG Brush or roller Monthly or as Required
15 Wire rope (loadline) EP-OGL Brush or spray Semi-Annually
16 Diffuser strainer, Hydraulic oil reservoir Clean Semi-Annually with Oil Change
18 Extend Sheaves. EP-MPG Grease Gun Weekly
19 Retract Sheaves. EP-MPG Grease Gun Weekly
20 Wire Rope Extension Cables WRL Spray or Brush
Any Time Boom is
Disassembled or 5 Years
21 Boom Wear Pads (Not Shown) EP-MPG See Boom Lubrication Monthly or as Required
Item Application
Recommended
Lubricant
Procedure Frequency
DANGER
Do not, under any circumstances, work at an elevated
height without using proper fall protection as required by
local, state or federal regulations.
Reference Only
