CONTROLS AND OPERATING PROCEDURES OPERATOR MANUAL NBT60L
3-6 Published 09-06-2019 Control # 691-01
FIGURE 3-1
6
5
2
1
4
7448-1
7459-16
5
5
5
7
7
9697
3
3
3
9
9593
8
10
Illustration for reference only.
Your crane may be different.
11
9594
Item Description Item Description
1 Outrigger Midspan Selector Pin 7 Outrigger Extend/Retract Cylinder
2 Outrigger Beam Assy Long 8 Console Panel
3 Outrigger Beam Assy Short 9 Emergency Stop Switch
4 Level Indicator 10 Cab Outrigger Controls Panel
5 Outrigger Jack Cylinder
11 Outrigger 75% Selector Pin (NTC60L Only)
6 Ground Station Outrigger Controls
