46 Part Number 80-1505-3 6/11
B. Line Set Rise or Drop
35 ft. (10.7 m) Rise: The maximum distance the CVD
®
Condensing Unit can be above the ice machine.
15 ft. (4.5 m) Drop: The maximum distance the CVD
®
Condensing Unit can be below the ice machine.
SV1751
35 FT. (10.7 M)
MAXIMUM
DISTANCE
SV1750
15 FT. (4.5 M)
MAXIMUM
DISTANCE
