Inside of Bin Thermostat Control
P4 Jumper
The P4 jumper labeled Jump 1 is used to set the
control for heating or cooling mode. Jump 2 is used to
establish Setpoint at either cut-in or cutout.
115V
240V
COM
NC
NO
C
P5
P5
RED LEAD
SENSOR
PROBE
BLACK
LEAD
SENSOR
PROBE
MATCH
WIRING
TO ICE
MACHINE
VOLTAGE
BIN SWITCH
WIRE
(WHITE)
BIN SWITCH
WIRE
(RED)
KEYPAD
JUMPER
LOCATION
P4
Jump 1
Jump 2
Cooling Mode
Cut-Out at Setpoint
Jumpers on
Left Pins
Only
