Part Number 80-1505-3 6/11 91
IB620C/IB680C/IB820C/IB1020C
A. Remove the splash shield
• Remove quarter turn connector from the right side
of splash shield.
• Gently bow the center of the splash shield and lift
up and forward to remove.
B. Remove the water curtain
• Gently flex the curtain in the center and remove it
from the right side.
• Slide the left pin out.
C. Remove the ice thickness probe
• Compress the hinge pin on the top of the ice
thickness probe.
• Pivot the ice thickness probe to disengage one pin
then the other. The ice thickness probe can be
cleaned at this point without complete removal. If
complete removal is desired, disconnect the ice
thickness control wiring from the control board.
D. Remove the water level probe
• Loosen the screw that holds the water level probe
in place. The probe can easily be cleaned at this
point without complete removal. If complete
removal is desired, remove the top cover, left and
right side panels and control box cover. Disconnect
the wire lead from the control board inside the
electrical control box.
