146 Part Number 80-1505-3 6/11
Quad Expansion Valve – S3070C
Operational Analysis 1 2 3 4
Ice Production
Air-Temperature Entering Condenser_____________
Water Temperature Entering Ice Machine_________
Published 24 hour ice production________________
Calculated (actual) ice production_______________
NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice production is within
10% of charted capacity.
Installation and Water System
All installation and water related problems must be corrected before proceeding with chart.
Ice Formation Pattern
Evaporators are numbered left
to right viewed from the front of
the ice machine
Evaporator #1______________
Evaporator #2______________
Evaporator #3______________
Evaporator #4______________
Ice formation is normal
Ice formation is
extremely thin on outlet
of 1 or more
evaporators
-or-
No ice formation on
entire evaporator
Ice formation normal
Ice formation normal
or
No ice formation on
entire evaporator
To Next Page
