128 Part Number 000007661 6/13
ELECTRICAL DIAGNOSTIC FLOWCHART
YES
YES
Control Board
PWR Light On?
Replace Control Board
NO
Bin Thermostat
Closed?
NO
Replace Thermostat
Ice Contacting
Thermostat?
Remove Ice - Allow
To Warm And Retest
Adjusting Closes
Thermostat?
Verify New Setting Cycles
Machine On/Off
Yes
No No
Yes
Power Supplied to Ice
Machine Control board?
Plug In Ice Machine, Reset BreakerNO
YES
Bin Empty (BE)
Light On?
NO YES
Electrical Flowchart – RN0400
