292 Part Number 80-1479-3 7/10
Quad Evaporator Ice Machines
ICE PROBE
WATER LEVEL PROBE
HARVEST VALVES
FUSE 7A
CLEAN (YELLOW)
HARVEST (RED)
WATER LEVEL (GREEN)
WATER SOLENOID (RED)
LIQUID SOLENOID (RED)
DUMP VALVE (RED)
WATER PUMP (RED)
CURTAIN SWITCH 4 (GREEN)
CURTAIN SWITCH 3 (GREEN)
CURTAIN SWITCH 2 (GREEN)
CURTAIN SWITCH 1 (GREEN)
HARVEST VALVE 1 (RED)
HARVEST VALVE 2 (RED)
HARVEST VALVE 3 (RED)
HARVEST VALVE 4 (RED)
CURTAIN SWITCHES
TOGGLE
SWITCH
LOW PRESSURE SWITCH
&
OPTIONAL BIN THERMOSTAT
AC LINE
VOLTAGE PLUG
