Part Number 80-1479-3 7/10 29
Component Identification
S Model Single Evaporator Models
WATER CURTAIN
CONTROL BOX
WATER
DISTRIBUTION
TUBE
TOGGLE
SWITCH
WATER
TROUGH
REFRIGERATION
ACCESS VALVES
ICE
THICKNESS
CONTROL
EVAPORATOR
WATER LEVEL
PROBE
WATER PUMP
WATER INLET
LOCATION, THE
WATER INLET VALVE
IS LOCATED IN THE
REFRIGERATION
COMPARTMENT
