162
Part Number 80-01111-9
7/10
Bin Switch Remov
al — QM45/Q130
1.
Discon
nect power to
the ice machine
at service
disconnect.
2.
Discon
nect bin switch wires in control
bo
x.
3.
Dep
ress tab on right side of evaporator with
thumb.
4.
Slide
bin switch to
right to remove.
5.
Pull wi
ring into evaporator compartment.
Bin Switch Removal
SV1731H
BIN SWITCH
TA
B
161
