Part Number 80-01111-9 7/10 229
SM50
FUSE (7A)
TRANSFORMER
BIN LIGHT
CONNECTION
DISPLAY BOARD
CONNECTION
THERMISTOR
BIN LIGHT
SWITCH
BIN THERMOSTAT
CONNECTION
