Part Number 80-01111-9 7/10 233
Q170/Q210/Q270 Tubing Schematic
SV3023
HEAT
EXCHANGER
STRAINER
COMPRESSOR
DRIER
EVAPORATOR
HOT GAS
SOLENOID VALVE
AIR OR
WATER
CONDENSER
EXPANSION
VALVE
RECEIVER
(WATER COOLED ONLY)
