54 Part Number 80-01111-9 7/10
H. Remove the ice damper.
Q130
• Grasp left side of ice damper and apply
p
ressure against the right-hand ice damper
mounting bracket.
• Pull forward on the ice damper until the left-
h
and mounting pin disengages.
Installation
• Grasp the right side of ice damper and place
le
ft hand pin in the mounting bracket.
• While applying pressure against the left-hand
mo
unting bracket push the damper until the
right-hand mounting pin engages.
Q170/Q210/Q270
To Next Page
