Part Number 80-01111-9 7/10
63
C.
Remove the W
a
ter Pump
•
Disconnect the wa
ter pump
power cord.
•
Loosen the scre
ws that hold the water pump in
place.
•
Lift
the water pump and bracket assembly up and
off the screws.
Removing the W
ater Pum
p
D.
Remove the W
ater
T
rough
•
Remove
the
screws
hol
ding the water
trough
to
the
walls of the cabinet.
WA
T
E
R
PUMP
SCREWS
SV3019
REMOVE SCREWS
62
64
