RDE 92500-02-R/08.94

14 Brueninghaus Hydromatik

Reparaturanleitung A11VO

Repair Instructions A11VO

30 Verschlußring komplett ausbauen.

Remove completely cover ring.

31 Triebwelle auspressen.

Press out drive shaft.

32 Schwenkwiege mit Lager und

Lagerschalen ausbauen.

Remove swivel cradle with bearing

as well as bearing case.

Triebwerk ausbauen

Remove rotary group
