AVS 3010 RANGE INSTALLATION MANUAL – VER 3
2
Contents
Note: items in red have been added or amended for this version of the installation manual.
Introduction
3
General system functions
• Arming the system
• Arming the system with the shock sensor disabled (AVS 3010+)
• Error zone report
• Error zone table
• Disarming the system
• Triggered zone report
• Triggered zone table....................................................................................................................................................................................................................
• Panic/Car finder
• Boot release
• Auto arm/Immobilisation
• Automatic re-arm and re-lock
• In car lock
3
4
Additional features
• Shock sensor (two stage) adjustment (AVS 3010+)
• Battery back up siren (AVS 3010+)
4
Remote controls
5
Emergency disarm / PIN code override
5
Wiring instructions
• Location of main control unit
• Plug connections
6
3010+ Battery back up siren wiring (BBSM)
7
Changing programmable features
7
Programming features
• Current sense
• Auto arm/immobilisation
• Auto re-arm and re-lock..............................................................................................................................................................................................................
• Arm and disarm chirp
• CDL pulse time
• Arming delay timer
• Pin code override
• Exit programming mode
7
8
Central door lock diagrams
• Negative pulse CDL system
• Positive pulse CDL system
• Reverse polarity CDL system
• Vacuum CDL system
• Single wire CDL system
• Flow thru CDL system..................................................................................................................................................................................................................
9
10
Additional AVS interior piezo wiring
10
