29
External device connection diagram
DVD
Set-top boxes
HDMI
HDMI
VIDEO R L
OUTPUT
HDMI input connection
VIDEO R L
INPUT
AV input connection
AV output connection
VIDEO R L
INPUT
Y Pb Pr
INPUT
AV input connection
USB connection
TV connection
Set-top boxes
SCART connection
AV input connection
EN
