1
G
ENERAL
The N73CG a is compact, pocket-sized 3½ digit multimeter for
measuring DC and AC voltage, DC current, resistance, diode function,
temperature, transistor function and includes an audible continuity test
function. Full range overload protection and low battery voltage indication
are provided. It is the ideal instrument for use in the laboratory, the
workshop and for hobby and home applications.
FRONT PANEL DESCRIPTION
1. FUNCTION AND RANGE SWITCH
This switch is used to select the function and desired range as well
as to turn on the instrument.
To extend the life of this battery, the switch should be in the "OFF"
position when the instrument is not in use.
2. DISPLAY
3½ digit, 7 segment, 0.5" high LCD.
3. "Common" SOCKET
Plug in connector for black (negative) test lead.
4. "V
Ω
mA" SOCKET
Plug in connector for red (positive) test lead for all voltage,
resistance and current (except 10A) measurements.
5. "10A" SOCKET
Plug in connector for red (positive) test lead for 10A current
measurement.
SPECIFICATIONS
Accuracies are guaranteed for 1 year
(storage conditions: 23
℃±
5
℃
, less than 75% RH).
DC VOLTAGE
RANGE RESOLUTION ACCURACY
200mV 100
μ
V
±
0.5% of rdg
±
2D
2000mV 1mV
±
0.5% of rdg
±
2D
20V 10mV
±
0.5% of rdg
±
2D
200V 100mV
±
0.5% of rdg
±
2D
600V 1V
±
0.8% of rdg
±
2D
