In the above schematic, the toroidal transformer has two secondaries for supplying the power amplifiers (one for
each channel) and three additional windings to supply the other components, which are connected to the P800
board. Below is a photo of this board:
Note that this board has its original capacitors, as they hadn't yet been replaced at the time of the photo. In the
circuit shown in the Service Manual, the transformer is connected to the board using the two connectors below:
If the schematic was correct, then the connections would have the color sequence indicated below:
