30
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
GND102 nsp nsp TERMINAL ALL PBST/GND PLATE-REEL 3790040876010
IC101 *HU100590R *HU100590R IC CPU MICRO
PROCESS
CXP82532-306Q/QFP80 CC4300 DWP367 J020825323060
IC102 *HC108040R *HC108040R IC OPTICAL-DSP CXD3017Q QFP80 /P236V J031301700020
IC103 *HC108070R *HC108070R IC ANALOG CXA2571N-T4 RF MATRIX AMP /CDP J080257100010
IC104 *HC000060R *HC000060R IC LOGIC TC74HCT7007AF/MFP14P J040747007010
IC105 *HC107400R *HC107400R IC LINEAR-DRIVER BA5979S/DIP32P J127597900020
IC106 *HC108080R *HC108080R IC LINEAR OP NJM2114D-DIP8P J121211400010
IC107 *HC108050R *HC108050R IC LOGIC-D/A CONVER IC SM5882AS SOP 8P J042588200010
IC108 *HC107410R *HC107410R IC LINEAR-DRIVER BA6956AN SIP9 /MOTOR DRIVER J127695600010
IC109 *HC107410R *HC107410R IC LINEAR-DRIVER BA6956AN SIP9 /MOTOR DRIVER J127695600010
IC110 *HC107380R *HC107380R IC LINEAR OP NJM2068MD-SOP8P J121206800030
J101 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J102 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J103 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J104 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J105 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J106 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J107 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J108 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J109 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J110 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J111 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J112 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J113 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J114 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J115 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J116 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J117 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J118 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J119 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J120 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J121 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J122 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J123 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J124 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J125 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J126 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J127 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J128 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J129 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J130 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J131 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J132 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J133 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J134 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J135 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J136 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J137 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J139 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J140 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J141 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J142 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J143 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J144 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J145 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
J146 nsp nsp CN WIRE 1P JUMPER (0.6/52MM) L045084006040
