4-1
CS 53 108
MECHANICAL INSTRUCTIONS
1) Loosen 7x screw as shown in picture 1.
picture 1
picture 2
2) Lift top cover as shown in picture 2.
3) Remove top cover.
Dismantling Top Cover
