Marantz DV7000 - 1.9 Waveform; 9. Waveform

1-12
9. WAVEFORM
Power requirements (Refer the circuit diagram page 1-25 and 1-26)
100V AC 120V AV 220V AC
1
2
3
4
1
2
3
4
1
2
3
4
50V 5µsec 50V 5µsec 100V 5µsec
10V 5µsec 10V 5µsec 10V 5µsec
5V 5µsec 5V 5µsec 5V 5µsec
0.1V 5µsec 0.1V 5µsec 0.1V 5µsec
