Marantz DV7000 - Page 27

37
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R883 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R884 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R885 /N 4822 051 30181 CHIP 180Ω ±5% 1/16W NN05181610
R886 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R887 /N 4822 051 30181 CHIP 180Ω ±5% 1/16W NN05181610
R888 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R889 /N 4822 116 83829 CHIP 270Ω ±5% 1/16W NN05271610
R890 /N 4822 116 83829 CHIP 270Ω ±5% 1/16W NN05271610
R891 /N 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
R892 /N 4822 051 30101 CHIP 100Ω ±5% 1/16W NN05101610
R893 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R894 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
R895 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R896 /N 4822 051 30181 CHIP 180Ω ±5% 1/16W NN05181610
R897 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R898 /N
/N 4822 051 30221 CHIP 220Ω ±5% 1/16W NN05221610
R903 /N
R904 /N 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R905 /N 4822 051 30102 CHIP 1kΩ ±5% 1/16W NN05102610
R906 /N
/N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R909 /N
R951 /N 4822 051 30474 CHIP 470kΩ ±5% 1/16W NN05474610
R952 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R953 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R954 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R955 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R956 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R957 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R958 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R959 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R960 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R961 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R962 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R963 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R964 /N 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R965 /N 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R968 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R969 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R970 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R971 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R972 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R973 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R974 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R975 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R976 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R977 /N 4822 051 30151 CHIP 150Ω ±5% 1/16W NN05151610
R978 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R979 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R980 /N 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R981 /N 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
R984 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R985 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
R986 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R987 /N 4822 117 12925 CHIP 47kΩ ±5% 1/16W NN05473610
R988 /N 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
R989 /N 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
R990 /N 4822 051 30103 CHIP 10kΩ ±5% 1/16W NN05103610
PE01-SEMICONDUCTORS
D801 /N 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
D802 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D803 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D805 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D807 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D808 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D809 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
D810 /N 4822 130 80346 CHIP DIODE 02CZ8.2 HZ30004050
Q801 /N 9965 000 05001 IC STV6411A
A/V SWITCH MATRIX
HC10008540
Q802
/N 4822 130 10698 CHIP TRS. 2SA1586 (Y GR) HX100012A0
Q807 2SA1576 (Q R)
Q808 /N 4822 130 60669 CHIP TRS. 2SC4081 (Q R)
2SC4116 (Y GR)
HX300012A0
Q809 /N 4822 130 60669 CHIP TRS. 2SC4081 (Q R)
2SC4116 (Y GR)
HX300012A0
Q810 /N 4822 130 10698 CHIP TRS. 2SA1586 (Y GR)
2SA1576A (Q R)
HX100012A0
Q811
/N 4822 130 60669 CHIP TRS. 2SC4081 (Q R) HX300012A0
Q814 2SC4116 (Y GR)
Q815 /N 4822 130 10698 CHIP TRS. 2SA1586 (Y GR)
2SA1576A (Q R)
HX100012A0
Q816
/N 4822 130 60669 CHIP TRS. 2SC4081 (Q R) HX300012A0
Q823 2SC4116 (Y GR)
Q952
/N 4822 130 63601 CHIP TRS. 2SC4213 HX342132A0
Q959
Q960 /N 4822 130 60669 CHIP TRS. 2SC4081 (Q R)
2SC4116 (Y GR)
HX300012A0
Q961 /N 4822 130 60669 CHIP TRS. 2SC4081 (Q R)
2SC4116 (Y GR)
HX300012A0
Q962 /N 4822 130 61903 DIG.TRS. DTA114EU BA10026210
PE01-MISCELLANEOUS
F801 /N 9965 000 04998 EMI FILTER NFM41R01C221 FM31221020
F802 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
F803
/N 9965 000 04998 EMI FILTER NFM41R01C221 FM31221020
F808
F809 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
F810
/N 9965 000 04998 EMI FILTER NFM41R01C221 FM31221020
F814
F952 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
F953 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
F954 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
F955 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
F956 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
F957 /N 4822 051 30471 CHIP 470Ω ±5% 1/16W NN05471610
F958 /N 4822 051 30121 CHIP 120Ω ±5% 1/16W NN05121610
F959 /N 4822 051 30121 CHIP 120Ω ±5% 1/2W NN05121610
J801 /N 9965 000 04999 JACK FFC 23FMN-BTRK(ST) YJ07019470
J802 /N 9965 000 05000 TERMINAL YKF41-5019
EUROCONNECTOR(21X2)
YT02420010
L801
/N 4822 157 60445 CHOKE COIL SUBSTITUDE LC11533900
L804 COIL 15µH J%
L805 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L806 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L807 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L808 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L809 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L810 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L811 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L812 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L813 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L814 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L815 /N 9965 000 00458 CHOKE COIL 8.2µH EL0405 LC18223900
L816 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
L951 /N 4822 157 60445 CHOKE COIL 15µH J% LC11533900
