Specifications
o
Audio section
0
Analog output [DSD] [PCM]
Channels: 2-channel 2-channel
Playable frequency range: 2 Hz – 100 kHz 2 Hz – 96 kHz (sampling frequency: 192 kHz)
2 Hz – 20 kHz (sampling frequency: 44.1 kHz)
Playable frequency response: 2 Hz – 50 kHz (-3 dB) 2 Hz – 50 kHz (-3 dB)
(sampling frequency: 192 kHz)
2 Hz – 20 kHz (sampling frequency: 44.1 kHz)
S/N: 113 dB (Audible range) 115 dB
Dynamic range: 110 dB (Audible range) 110 dB (24 bit)
101 dB (16 bit)
Harmonic distortion: 0.0010 % (Audible range) 0.0010 % (24 bit)
0.0016 % (16 bit)
Output level
Unbalanced output (FIXED):
Unbalanced output (VARIABLE):
2.2 V RMS
4.5 V RMS (variable maximum)
2.2 V RMS
4.5 V RMS (variable maximum)
Headphone output: 30 mW / 32 Ω/ohms (variable maximum) 30 mW / 32 Ω/ohms (variable maximum)
