53
TECHNICAL SPECIFICATIONS
Track System........................................... 4 Track, 2 Channel
Head System
Rec Play Head ........................................Hard Permalloy
Erase Head ........................................... Dual Gap Ferrite
Approx Head Life .................................................. 1000H
Recording/Erasure System ........................ AC 105 kHz Bias
Motor System
Capstan ................................ DC Servo Controlled Motor
Reel .................................................................. DC Motor
Overall S/N, NR off, ”A” weighted
Normal ..................................................................... 57dB
High ......................................................................... 58dB
Metal ........................................................................ 58dB
Overall S/N, Dolby C NR, ”A” weighted
Normal ..................................................................... 74dB
High ......................................................................... 75dB
Metal ........................................................................ 75dB
Frequency Response, Rec/Play, NR off
Normal ......................................................... 40Hz–16kHz
High ............................................................. 40Hz–17kHz
Metal ............................................................ 40Hz–18kHz
Dolby NR effect, B/C , S/N improvement,
CCIR/ARM weighted .................................. B 8dB, C 17dB
Output
Line....................................................................... 540mV
Phone ..................................................................... 50mV
Output Impedance
Line............................................................................47Ω
Phone ...................................................................... 120Ω
Input Sensitivity
Line....................................................................... 100mV
Input Impedance
Line........................................................................ 100kΩ
Fine Speed Control ........................................................ ± 3%
Wow & Flutter
W RMS...................................................0.07% (Jis WTD)
Power Supply
Power Requirement .................................. 120V AC 60Hz
Power Consumption ............................................... 0.25A
Dimensions
Width ................................................ 19 inches (483mm)
Height .......................................... 5
3/16 inches (132mm)
Depth ........................................... 13
3/8 inches (340mm)
Net Weight ..................................................... 15.4 lbs. (7kg)
Specifications subject to change without prior notice.
RC-5 Command Table
Command RC-5 Code
0 1800
1 1801
2 1802
3 1803
4 1804
5 1805
6 1806
7 1807
8 1808
9 1809
Next 1832
Previous 1833
Monitor Select 1838
Recording Pause 1840
Record Blank 1842
Mechanism A 1844
Mechanism B 1846
Pause 1848
Auto Rewind 185000
Play 1853
Normal Speed 185311
High Speed 185312
Stop 1854
Wind 1852
Rewind 1850
Record 1855
Auto Bias 185509
A+B Synchronous Recording 185510
Connect 1856
Disconnect 1857
