Marantz SM-17 - Page 12

14
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C910 /N,/S 4822 124 12276 FILM 0.01µF
±
5% 100V PP OF15103540
C951 4822 122 40617 CER. 50V DC 0.1µF +80 -20% DD38104010
C952 4822 124 41543 ELECT. 1µF M 50V OA10505020
C953 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
P801-RESISTORS
R801 4822 050 21108 1
Ω ±
5% 1/2W GG05010120
R802 4822 050 21108 1
Ω ±
5% 1/2W GG05010120
R803 4822 052 10101 100
Ω ±
5% 1/6W GG05101160
R804 4822 052 10101 100
Ω ±
5% 1/6W GG05101160
R807 4822 050 24708 4.7
Ω ±
5% 1/4W GG05047140
R808 4822 050 24708 4.7
Ω ±
5% 1/4W GG05047140
R809 4822 117 10158 1
Ω ±
5% 1/4W GG05010140
R810 4822 052 10101 100
Ω ±
5% 1/6W GG05101160
R812 4822 050 24708 4.7
Ω ±
5% 1/4W GG05047140
R814 4822 113 90119 FUSE 22
Ω ±
2% 1/4W NF02220140
R816 4822 052 10478 4.7
Ω ±
5% 1/6W GG05047160
R913 4822 053 10109 10
Ω ±
5% 1W GA05100010
R914 4822 053 10109 10
Ω ±
5% 1W GA05100010
R917 4822 053 10331 330
Ω ±
5% 1W GA05331010
R918 4822 053 10331 330
Ω ±
5% 1W GA05331010
R951 4822 052 10109 10
Ω ±
5% 1/6W GG05100160
R955 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
P801-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : R805 R806 R811
R815 R817 R901-R912
R952-R959
P801-SEMICONDUCTORS
D801
4822 130 80839 DIODE S5688G HD20029050
D808 VRM=400V I0=1A
D809 4822 130 10851 ZENER DIODE HZ24-2L HD30012010
D810 4822 130 10851 ZENER DIODE HZ24-2L HD30012010
D811 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D812 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D813 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D814 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D815 4822 130 80116 ZENER DIODE 24V HD32401000
D819 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D820 4822 130 80839 DIODE S5688G
VRM=400V I0=1A
HD20029050
D901 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
D951 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D952 4822 130 33948 ZENER DIODE 5.6V HD30561000
Q801 4822 130 11605 TRS. 2SD1415 HT41415100
Q802 4822 130 11604 TRS. 2SB1020 HT21020100
Q803 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q804 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q805 4822 130 11605 TRS. 2SD1415 HT41415100
Q806 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q901 4822 209 83312 IC TA7317P HC10042050
Q951 4822 130 42836 F.E.T. 2SK246 GR HF202461C0
Q952 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q953 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q954 4822 130 60117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
Q955 4822 209 83679 IC DUAL OP-AMP NJM2904 HC10030090
P801-MISCELLANEOUS
G801 4822 121 20263 CAP.COMP. 0.47µF + 6.8
Ω
NOISE KILLER
BF47400010
L801 4822 158 60605 FERRIT BEADS B-01-RT FC90050060
L901 4822 280 70354 RELAY VB 24MBU-510
5A/240VAC
LY20240310
L905 4822 158 60605 FERRIT BEADS B-01-RT FC90050060
U804 4822 158 60605 FERRITE BEADS B-01-RT FC90050060
P861 P861-RECTIFIER
CIRCUIT BOARD
WA314J1050
D861 9965 000 01578 DIODE D25XB60
600V 25A BRIDGE-DI
HE20029290
G861 4822 121 20263 CAP.COMP. 0.47µF + 6.8
Ω
NOISE KILLER
BF47400010
P871-ACOUTLET
CIRCUIT BOARD
[ /F,/U VERSION ]
J871 /F,/U JACK MAINS OUTLET
CCT1306-0212
YJ04001840
P891-POWER SW
CIRCUIT BOARD
C891 4822 121 43732 FILM 0.01µF 250V AC DF77103500
S891 4822 276 12647 PUSH SW. ESB-99753V-4 TV-8 SP01011470
PM01-HDAM CIRCUIT BOARD
FOR Q601 Q701
PM01-RESISTOR
RM09 4822 100 20681 TRIM. 2.2k
Ω
RH0638CJ3R RA02220780
PM01-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : RM01-RM08
PM01-SEMICONDUCTORS
DM01
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DM05 30V 0.1A
QM01 5322 130 41844 F.E.T. 2SK170 BL
VGDS=-40V PD=0.4V
HF201701G0
QM02 5322 130 41844 F.E.T. 2SK170 BL
VGDS=-40V PD=0.4V
HF201701G0
QM03 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
QM04 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QM05 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
QM06 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
