Marantz SM-17 - Page 7

9
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
001B /F1N FRONT PANEL ASSY SM-17SA
GOLD HAIR
314J248520
001B /N1G 9965 000 01840 FRONT PANEL ASSY SM-17
GOLD BLAST
314J248510
001B /N1B 9965 000 01835 FRONT PANEL ASSY SM-17
BLACK BLAST
314J248500
001B /S1G FRONT PANEL ASSY SM-17SA
GOLD BLAST
314J248540
001B /U1B FRONT PANEL ASSY SM-17SA
BLACK BLAST
314J248530
003B GOLD 4822 426 10497 ESCUTCHEON GOLD 269J063110
003B BLACK 4822 426 10496 ESCUTCHEON BLACK 269J063010
013B 4822 404 21012 JOINT LINK FOR POWER 025J125010
014B / GOLD 4822 410 11276 BUTTON POWER GOLD 176J270150
014B BLACK 4822 410 11275 BUTTON POWER BLACK 176J270050
022B /F BADGE FOR SUPER AUDIO 318J251010
023B GOLD 9965 000 01554 NEW MARANTZ BADGE GL 313J251110
023B BLACK 9965 000 01553 NEW MARANTZ BADGE BL 313J251010
024B /S, /U S A BADGE 318J251020
001D GOLD 4822 442 01018 LID TOP GOLD 269J257110
001D BLACK 4822 442 01017 LID TOP BLACK 269J257010
002D GOLD 4822 502 14425 SCREW FOR TOP LID GOLD 323S010020
002D BLACK 4822 502 21693 SCREW FOR TOP LID BLACK 323S010030
003D GOLD 4822 426 10499 SIDE PANEL GOLD 269J249110
003D BLACK 4822 426 10498 SIDE PANEL BLACK 269J249010
004D GOLD 4822 502 14425 SCREW FOR SIDE PANEL
FRONT GOLD
323S010020
004D BLACK 4822 502 21693 SCREW FOR SIDE PANEL
FRONT BLACK
323S010030
009D GOLD 4822 502 14462 SCREW FOR TOP LID REAR
PANEL
318K010020
009D BLACK 4822 502 14461 SCREW FOR TOP LID REAR
BLACK
318K010030
010D GOLD 4822 502 14462 SCREW FOR SIDE PANEL
REAR GOLD
318K010020
010D BLACK 4822 502 14461 SCREW FOR SIDE PANEL
REAR BLACK
318K010030
002G LID BOTTOM 313J257020
003G 4822 462 42134 LEG 291K057010
C001 9965 000 01557 ELECT 15000µF 63V x 2
FOR AUDIO
EI15906350
F001 /F FUSE 10A 250V MITI GRU FS11000570
F001 /N,/S 4822 070 35002 FUSE 5A 250V BS LISTED FS10500850
F001 /U FUSE 10A 250V FS11000530
J003 4822 265 11424 TERMINAL SPK. RED YT01010360
J004 4822 265 11425 TERMINAL SPK. WHT YT01010370
J005 4822 265 11424 TERMINAL SPK. RED YT01010360
J006 4822 265 11425 TERMINAL SPK. WHT YT01010370
J007 /F,/U JACK FUSE HOLDER
10A 250V 31.8MM
YJ08000600
J007 /N,/S 4822 267 31818 JACK FUSE HOLDER
H201 20MM
YJ08000610
J008 4822 265 11399 JACK AC INLET SOT-16C YJ04002360
L001 /F MAINS TRANSFORMER TS42002120
L001 /N,/S 9965 000 01558 MAINS TRANSFORMER TS42002130
L001 /U MAINS TRANSFORMER TS42002150
W001 /F MAINS CORD
MITY DC-302-J 12A
ZC01802080
W001 /N 4822 321 11439 MAINS CORD
2P10A 250V CLASS2
ZC01803080
W001 /S MAINS CORD ZC01804070
W001 /U MAINS CORD
UL/CSA 10A 125V
ZC01803100
PACKING
001T /F USER GUIDE 314J851110
001T /N 9965 000 01591 USER GUIDE 314J851310
001T /S USER GUIDE 314J851350
001T /U USER GUIDE 314J851250
NOT STANDARD SPARE
PARTS
001S /F,/U PACKING CASE SM-17SA 314J801010
002S CUSHION FOR LEFT 314J809010
003S CUSHION FOR RIGHT 314J809020
