Marantz SR7015 User Manual

.
u
wqytre
A
Power operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 94)
B
Power indicator
This is lit as follows according to the power status:
0
Off: Power on
0
Red: Normal standby
0
Orange:
0
When “HDMI Pass Through” is set to “On” (v p. 194)
0
When “HDMI Control” is set to “On” (v p. 196)
0
When “Network Control” is set to “Always On” (v p. 250)
C
INPUT SELECTOR knob
This selects the input source. (v p. 94)
D
Main display
This displays various pieces of information. (v p. 23)
E
Remote control sensor
This receives signals from the remote control unit. (v p. 9)
F
VOLUME knob
This adjusts the volume level. (v p. 95)
G
Door
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents
Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

Marantz SR7015 Specifications

General

Channels	9.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	165W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	235W
70% Guarantee	Yes
Audio Inputs	8
Multi-Channel Preamp Outputs	11.2
Subwoofer Out	2
HDMI Outputs	3
HDMI 2.1 Support	Yes
4K/120Hz Pass-Through	Yes
8K/60Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Speaker Calibration	Audyssey MultEQ XT32
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
Roon Tested	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Ethernet	Yes
USB Port	1 (front)
Phono Input	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Digital Inputs	2 Optical, 2 Coaxial
Zone Audio Output	2
HDMI Inputs	8 (1 front)
Speaker Terminals	11 (8 assignable)
Weight	14.8 kg
