Marantz SR7015 User Manual

o
Crossover
Set the maximum frequency of the bass signal output from each
channel to the subwoofer.
40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz /
180 Hz / 200 Hz / 250 Hz (Default: 80 Hz)
0
This can be set when “2ch Playback” - “Subwoofer” is set to “Yes”.
0
When “2ch Playback” - “Front” is set to “Large” and “SW Mode” is set to “LFE”,
“Full Band” is displayed and this cannot be set.
o
Distance FL / Distance FR
Set distance from main listening position to speaker.
0.00 m – 18.00 m (Default : 3.60 m) /
0.0 ft – 60.0 ft (Default : 12.0 ft)
0
Set the difference in the distance between the speakers to less than 6.00 m
(20.0 ft).
o
Level FL / Level FR
Adjust the level of each channel.
-12.0 dB – +12.0 dB (Default: 0.0 dB)
Contents Connections Playback Settings Tips Appendix
243
Front panel Display Rear panel Remote Index

Marantz SR7015 Specifications

General

Channels	9.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	165W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	235W
70% Guarantee	Yes
Audio Inputs	8
Multi-Channel Preamp Outputs	11.2
Subwoofer Out	2
HDMI Outputs	3
HDMI 2.1 Support	Yes
4K/120Hz Pass-Through	Yes
8K/60Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Speaker Calibration	Audyssey MultEQ XT32
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
Roon Tested	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Ethernet	Yes
USB Port	1 (front)
Phono Input	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Digital Inputs	2 Optical, 2 Coaxial
Zone Audio Output	2
HDMI Inputs	8 (1 front)
Speaker Terminals	11 (8 assignable)
Weight	14.8 kg
