Connecting 11.1-channel speakers
This system, which is based on a 5.1-channel system, plays back up to
11.1-channels at the same time.
You can connect speakers for 11-channels for MAIN ZONE by using an
external power amplifier.
o
Example connection when using two sets of
ceiling speakers
.
C
FL FR
SBL
SBR
SW
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v p. 227)
.
FR FL C SR SL
SW
SBR SBL
Power amplifier
TRR TRL
HEIGHT 2
z
HEIGHT 1
z
TFR TFL
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 67)
0
You can connect the external power amplifier to the Front channel instead of the
Height2 channel. Use the “Pre-out” setting in the menu to set the channel
connected to the external power amplifier. (v p. 231)
