Marantz SR7015 User Manual

Connecting a TV
Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit.
How to connect a TV depends on the connectors and functions equipped on the TV.
ARC (Audio Return Channel) / eARC (Enhanced Audio Return Channel) function plays TV audio on this unit by sending the TV audio signal to this unit via
HDMI cable.
.
No
Yes
Is the TV equipped with an HDMI connector?
Yes No
Is the TV compatible with the ARC / eARC?
“Connection 1 : TV equipped with an HDMI
connector and compatible with the ARC (Audio
Return Channel) / eARC (Enhanced Audio
Return Channel)” (v p. 77)
“Connection 2 : TV equipped with an HDMI
connector and incompatible with the ARC (Audio
Return Channel) / eARC (Enhanced Audio Return
Channel)” (v p. 78)
“Connection 3 : TV equipped without
an HDMI connector” (v p. 79)
Contents Connections Playback Settings Tips Appendix
76
Front panel Display Rear panel Remote Index

Marantz SR7015 Specifications

General

Channels	9.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	165W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	235W
70% Guarantee	Yes
Audio Inputs	8
Multi-Channel Preamp Outputs	11.2
Subwoofer Out	2
HDMI Outputs	3
HDMI 2.1 Support	Yes
4K/120Hz Pass-Through	Yes
8K/60Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Speaker Calibration	Audyssey MultEQ XT32
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
Roon Tested	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Ethernet	Yes
USB Port	1 (front)
Phono Input	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Digital Inputs	2 Optical, 2 Coaxial
Zone Audio Output	2
HDMI Inputs	8 (1 front)
Speaker Terminals	11 (8 assignable)
Weight	14.8 kg
