Marantz SR7015 User Manual

DC OUT jacks
When a device with DC IN jack is connected, the connected device’s power on/standby can be controlled through linked operation to this unit.
The DC OUT jack outputs a maximum 12 V DC/150 mA electrical signal.
.
12 V DC/150 mA trigger-compatible device
NOTE
0
Use a monaural mini-plug cable for connecting the DC OUT jacks. Do not use a stereo mini-plug cable.
0
If the permissible trigger input level for the connected device is larger than 12 V DC/150 mA, or has shorted, the DC OUT jack cannot be used. In this case, turn off the power
to the unit, and disconnect it.
Contents
Connections Playback Settings Tips Appendix
91
Front panel Display Rear panel Remote Index

Marantz SR7015 Specifications

General

Channels	9.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	165W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	235W
70% Guarantee	Yes
Audio Inputs	8
Multi-Channel Preamp Outputs	11.2
Subwoofer Out	2
HDMI Outputs	3
HDMI 2.1 Support	Yes
4K/120Hz Pass-Through	Yes
8K/60Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Speaker Calibration	Audyssey MultEQ XT32
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
Roon Tested	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Ethernet	Yes
USB Port	1 (front)
Phono Input	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Digital Inputs	2 Optical, 2 Coaxial
Zone Audio Output	2
HDMI Inputs	8 (1 front)
Speaker Terminals	11 (8 assignable)
Weight	14.8 kg
