Marantz SR8015 Quick Start Guide

7
3) Connect the receiver to your TV with
an HDMI cable
(ARC/eARC)
HDMI IN
HDMI OUT
MONITOR 1
(ARC/eARC)
ARC
MONITOR1
eARC
HDMI cable
Receiver (Rear panel)
ARC (Audio Return Channel) and eARC (Enhanced Audio
Return Channel) support:
If your TV supports ARC, your TV can send audio back to the AV receiver
when you are using your TV’s built-in video sources (TV tuner, Smart TV
streaming services, etc.) ARC requires that you enable HDMI CEC on your
TV. Please refer to your TV’s Owner’s Manual for instructions on how to
setup HDMI CEC. In addition, if your TV supports eARC, it can also send
back high bitrate audio formats such as Dolby TrueHD, Dolby Atmos,
DTS-HD Master Audio and DTS:X. Please refer to your TV’s Owner’s
Manual for additional information about enabling the eARC function.
4) Turn on the TV
TV remote control unit
5) Select the appropriate HDMI input on
your TV
HDMI
or
TV/
VIDEO
INPUT
TV remote control unit
1. SR8015N_QSG_ENG_00A_200519.indd 71. SR8015N_QSG_ENG_00A_200519.indd 7 2020/06/03 18:48:442020/06/03 18:48:44
PrintingColor:Black

Marantz SR8015 Specifications

General

Channels	11.2
Power Output	140 W (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	175 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	250 W
70% Guarantee	Yes
Total Harmonic Distortion	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
HDMI Inputs	8
HDMI Outputs	3
HDMI Version	2.1
8K/60Hz Pass-Through	Yes
4K/120Hz Pass-Through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Auto Low Latency Mode (ALLM)	Yes
Variable Refresh Rate (VRR)	Yes
Quick Frame Transport (QFT)	Yes
Dolby Atmos	Yes
Dolby Atmos Height Virtualization	Yes
DTS:X	Yes
DTS Virtual:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Multi-room	Yes
HEOS Built-in	Yes
AirPlay 2	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
USB Port	Yes
Phono Input	Yes
