Dimensions (W x H x D) Capacity Part#
262 - 280 x 460x 520mm (10 ⁵⁄ - 11 x 18 ¹⁄ x 20 ¹⁄”) 26L (2 X 13L) 04-MAX300-26S-AG
262 - 280 x 540 x 520mm (10 ⁵⁄ - 11 x 21 ¹⁄ x 20 ¹⁄”) 30L (2 X 15L) 04-MAX300-30S-AG
262 - 280 x 620 x 520mm (10 ⁵⁄ - 11 x 24 ¹³⁄ x 20 ¹⁄”) 32L (2 X 16L) 04-MAX300-32S-AG
Dimensions (W x H x D) Capacity Part#
412 - 430 x 460x 520mm (16 ¹⁄ - 16 ¹⁵⁄ x 18 ¹⁄ x 20 ¹⁄”) 56L (2 X 28L) 04-MAX450-56S-AG
412 - 430 x 540 x 520mm (16 ¹⁄ - 16 ¹⁵⁄ x 21 ¹⁄ x 20 ¹⁄”) 63L (2 x 15L + 1x 33L) 04-MAX450-63S-AG NEW!
412 - 430 x 540 x 520mm (16 ¹⁄ - 16 ¹⁵⁄ x 21 ¹⁄ x 20 ¹⁄”) 66L (2 X 33L) 04-MAX450-66S-AG
412 - 430 x 620 x 520mm (16 ¹⁄ - 16 ¹⁵⁄ x 24 ¹³⁄ x 20 ¹⁄”) 69L (2 x 16L + 1x 37L) 04-MAX450-69S-AG NEW!
412 - 430 x 620 x 520mm (16 ¹⁄ - 16 ¹⁵⁄ x 24 ¹³⁄ x 20 ¹⁄”) 76L (2 X 38L) 04-MAX450-76S-AG
Dimensions (W x H x D) Capacity Part#
362 - 380 x 460x 520mm (14 ¹⁄ - 14 ³¹⁄ x 18 ¹⁄ x 20 ¹⁄”) 48L (2 X 24L) 04-MAX400-48S-AG
362 - 380 x 540 x 520mm (14 ¹⁄ - 14 ³¹⁄ x 21 ¹⁄ x 20 ¹⁄”) 54L (2 X 27L) 04-MAX400-54S-AG
362 - 380 x 620 x 520mm (14 ¹⁄ - 14 ³¹⁄ x 24 ¹³⁄ x 20 ¹⁄”) 62L (2 X 31L) 04-MAX400-62S-AG
Dimensions (W x H x D) Capacity Part#
562 - 580 x 540 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 21 ¹⁄ x 20 ¹⁄”) 63L (2 x 15L + 1x 33L) 04-MAX600-63S-AG NEW!
562 - 580 x 540 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 21 ¹⁄ x 20 ¹⁄”) 66L (2x 33L) 04-MAX600-66S-AG NEW!
562 - 580 x 620 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 24 ¹³⁄ x 20 ¹⁄”) 69L (2 x 16L + 1x 37L) 04-MAX600-69S-AG NEW!
562 - 580 x 460 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 18 ¹⁄ x 20 ¹⁄”) 74L (2 X 13L + 2 X 24L) 04-MAX600-74S-AG
562 - 580 x 540 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 21 ¹⁄ x 20 ¹⁄”) 84L (2 X 15L + 2 X 27L) 04-MAX600-84S-AG
562 - 580 x 620 x 520mm (22 ¹⁄ - 22 ²⁷⁄ x 24 ¹³⁄ x 20 ¹⁄”) 94L (2 X 16L + 2 X 31L) 04-MAX600-94S-AG
Technical Specifications & Assembly
MAX BIN WASTE STORAGE SYSTEM
SERIES
M-Series Max Bin for 12” (300mm) cabinets
M-Series Max Bin for 16” (400mm) cabinets
M-Series Max Bin for 18” (450mm) cabinets
M-Series Max Bin for 24” (600mm) cabinets
Base Drilling Diagram
620 mm Height
540 mm Height
460 mm Height
620 mm Height
540 mm Height
460 mm Height
Fold the instruction sheet to the appropriate product height
option.
Measure from bottom edge of cabinet and use template to mark
holes with awl.
