99
CÓDIGO INTERFACE CABO OF XBC
A SINAL DE PARTIDA 2400 C6/3(VD) X2811/5
BC FAROL BAIXO LD 5401 C3/1 X2504/9
BD FAROL BAIXO LE 5402 C3/1 X2504/7
BE FAROL ALTO LD 5411 C3/2 X2504/8
BF FAROL ALTO LE 5412 C3/2 X2504/6
C RÉ 3400 BR X2811/6
CA LUZ DE RÉ LD 3401 C1/1 X2506/3
CB LUZ DE RÉ LE 3402 C1/1 X2507/3
D LUZ DE POSICAO 4414 X2811/3
DA
LUZ DE POSICAO
DIANTEIRA LD
4401 C2/2(VD) X2504/4
DB
LUZ DE POSICAO
DIANTEIRA LE
4402 C2/2(VD) X2504/3
DC
LUZ DE POSICAO
TRASEIRA LD
4431 C4/4(VD) X2506/1
DD
LUZ DE POSICAO
TRASEIRA LE
4432 C4/4(VD) X2507/1
DE
LUZ DE POSICAO
LATERAL LD
4411 C2/2(VD) X2509/1
DF
LUZ DE POSICAO
LATERAL LE
4412 C2/2(VD) X2508/1
EC PISCA DIANTEIRO LD 6401
C2/2(PR-
CI)
X2504/2
ED PISCA DIANTEIRO LE 6411
C2/2(PR-
BR)
X2504/1
EF PISCA TRASEIRO LD 6403
C4/3(PR-
CI)
X2506/5
EG PISCA TRASEIRO LE 6413
C4/3(PR-
BR)
X2507/5
EH PISCA LATERAL LD 6402
C2/2(PR-
CI)
X2509/2
EI PISCA LATERAL LE 6412
C2/2(PR-
BR)
X2508/2
F SINAL +15 2222 CI X2811/1
G SINAL VELOCIDADE 3500 B7/TAC. X2811/7
HA +15 LIMPADOR 7400
C6/3(PR-
LI)
X0106/2
CÓDIGO INTERFACE CABLE OF XBC
A SEÑAL DE PARTIDA 2400 C6/3(VD) X2811/5
BC FAROL BAJO LD 5401 C3/1 X2504/9
BD FAROL BAJO LI 5402 C3/1 X2504/7
BE FAROL ALTO LD 5411 C3/2 X2504/8
BF FAROL ALTO LI 5412 C3/2 X2504/6
C MARCHA ATRÁS 3400 BR X2811/6
CA
LUZ DE MARCHA ATRÁS LD 3401 C1/1 X2506/3
CB LUZ DE MARCHA ATRÁS LI 3402 C1/1 X2507/3
D LUZ DE POSICIÓN 4414 X2811/3
DA
LUZ DE POSICIÓN
DELANTERA LD
4401 C2/2(VD) X2504/4
DB
LUZ DE POSICIÓN
DELANTERA LI
4402 C2/2(VD) X2504/3
DC
LUZ DE POSICIÓN
TRASERA LD
4431 C4/4(VD) X2506/1
DD
LUZ DE POSICIÓN
TRASERA LI
4432 C4/4(VD) X2507/1
DE
LUZ DE POSICIÓN
LATERAL LD
4411 C2/2(VD) X2509/1
DF
LUZ DE POSICIÓN
LATERAL LI
4412 C2/2(VD) X2508/1
EC
INTERMITENTE
DELANTERO LD
6401
C2/2(PR-
CI)
X2504/2
ED
INTERMITENTE
DELANTERO LI
6411
C2/2(PR-
BR)
X2504/1
EF
INTERMITENTE TRASERO
LD
6403
C4/3(PR-
CI)
X2506/5
EG
INTERMITENTE TRASERO
LI
6413
C4/3(PR-
BR)
X2507/5
EH
INTERMITENTE LATERAL
LD
6402
C2/2(PR-
CI)
X2509/2
EI
INTERMITENTE LATERAL
LI
6412
C2/2(PR-
BR)
X2508/2
F SEÑAL +15 2222 CI X2811/1
G SEÑAL VELOCIDAD 3500 B7/TAC. X2811/7
HA +15 LIMPIADOR 7400
C6/3(PR-
LI)
X0106/2
CODE INTERFACE CABLE OF XBC
A START SIGNAL 2400 C6/3(VD) X2811/5
BC RH LOW HEADLIGHT 5401 C3/1 X2504/9
BD LH LOW HEADLIGHT 5402 C3/1 X2504/7
BE RH HIGH HEADLIGHT 5411 C3/2 X2504/8
BF LH HIGH HEADLIGHT 5412 C3/2 X2504/6
C REVERSE 3400 BR X2811/6
CA RH REVERSE LIGHT 3401 C1/1 X2506/3
CB LH REVERSE LIGHT 3402 C1/1 X2507/3
D CLEARANCE LIGHT 4414 X2811/3
DA
RH FRONT CLEARANCE
LIGHT
4401 C2/2(VD) X2504/4
DB
LH FRONT CLEARANCE
LIGHT
4402 C2/2(VD) X2504/3
DC
RH REAR CLEARANCE
LIGHT
4431 C4/4(VD) X2506/1
DD
LH REAR CLEARANCE
LIGHT
4432 C4/4(VD) X2507/1
DE
RH SIDE CLEARANCE
LIGHT
4411 C2/2(VD) X2509/1
DF
LH SIDE CLEARANCE
LIGHT
4412 C2/2(VD) X2508/1
EC
RH FRONT TURN
SIGNAL
6401
C2/2(PR-
CI)
X2504/2
ED
LH FRONT TURN
SIGNAL
6411
C2/2(PR-
BR)
X2504/1
EF RH REAR TURN SIGNAL 6403
C4/3(PR-
CI)
X2506/5
EG LH REAR TURN SIGNAL 6413
C4/3(PR-
BR)
X2507/5
EH RH SIDE TURN SIGNAL 6402
C2/2(PR-
CI)
X2509/2
EI LH SIDE TURN SIGNAL 6412
C2/2(PR-
BR)
X2508/2
F SIGNAL +15 2222 CI X2811/1
G SPEED SIGNAL 3500 B7/TAC. X2811/7
HA +15 WIPER 7400
C6/3(PR-
LI)
X0106/2
CHASSI MERCEDES CHASIS MERCEDES MERCEDES CHASSIS
