Technical data DDM3 - 230
Voltage 230 V
Power Input 1500 W
No load speed
1st gear 950 min
-1
2nd gear 1800 min
-1
3rd gear 3450 min
-1
Maximum drilling Gear Wet Dry
diameter with 1 ø61-200mm ø118-200mm
diamond core bits 2 ø33-60mm ø61-117mm
3 ø22-32mm ø22-60mm
Outer thread 1
1
/
4
” UNC (32mm) Inner thread
1
/
2
” BSP (19mm)
Spindle thread
Side handle clamp 60 mm
Weight 6.9 kg
Technical Data
Maximum diameter shown on the
label only applies to Marcrist
core drills. By using low quality
core drills the maximum usable
diameter will be reduced.
