JX-650W PARTS LIST
Part #
Description
QTY
Part #
Description
QTY
1
Base frame
1
28
End Cap
2
2
Running stage
1
29
10mm
×
1mm EVA
4
3
Left console mast
1
30
φ
40
×φ
10
×
2mm Washer
2
4
Right console mast
1
31
Flinger
3
5
Console frame
1
32
Switch box
1
6
M8 Aircraft nut
4
33
Motor belt
1
7
Front roller
1
34
End cap
2
8
Rear roller
1
35
Cushion
4
9
Motor support
1
36
Handle grip
2
10
Wheels
2
37
Rubber Cushion
1
11
Protective pipe
2
38
End cap
1
12
Running deck
1
39
End cap
2
13
Running belt
1
40
Cushion
1
14
Side rail
2
41
Shock pad
4
15
Console housing
1
42
Roller
2
16
Safety key cover
1
43
Washer
2
17
Display screen
1
44
Motor
1
18
Logo sticker
4
45
Safety key
1
19
Motor cover
1
46
Controller
1
20
Left mast cover Sticker
1
47
Lock Washer
1
21
Right mast cover sticker
1
48
M8×15mm Allen bolt
2
22
Left end cap
1
49
Switch
1
23
Right end cap
1
50
Fuse
1
24
Motor bottom cover
1
51
Power Socket
1
25
End cap
2
52
Power cord
1
26
Lock Pin
2
53
Short cords (Connectors of 47/48/49)
1
27
End Cap
2
54
M8×90mm Allen bolt
4
