Marcy CL503 - Parts List

15
PARTS LIST
PART NO. DESCRIPTION Q’TY
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Front Post 1
5 Handlebar 1
6 Computer 1
7 Seat Post 1
8 Seat 1
9 Left Pedal 1
10 Right Pedal 1
11 Quick Release Knob 1
12 Flat Washer Φ17
3
13 Spring Washer Φ12.5
3
14 Nylon Nut M8
3
15 Carriage Bolt M8*L65mm
2
16 Curve WasherΦ22
6
17 Domed Nut M8
2
18 Allen Bolt M8*15mm
8
19 Flat Washer Φ17
4
20 Tension Knob and Upper Tension Cable
1
21 Upper Computer Wire
1
22
Lower Computer Wire
1
23 Lower Tension Cable
1
24
Hand Pulse Wire
1
25 Crank Arm
1
26 T Knob
1
27 Allen Bolt M8*20
1
28 Transportation Wheel
2
29 Rear Stabilizer End Cap
2
30 Clamp
1
31 Flat Washer Φ25
2
32 Screw for Computer
2
