HG3000 PARTS LIST
PART NO DESCRIPTION SIZE QUANTITY
1 Upper Frame 1
2 Vertical Frame 1
3 Base Frame 1
4 Rear Stabilizer 1
5 Leg Developer Holder 1
6 Seat Support 1
7 Leg Developer 1
8 Front Press Base 1
9 Right Butterfly 1
10 Left Butterfly 1
11 Front Press Handle 2
12 Butterfly Cable Bracket 2
13 Arm Curl Stand 1
14 Swivel Pulley Bracket 2
15 Angled Double Floating Pulley Bracket 1
16 Weight Stack Cover 1
17 Guide Rod 2
18 Lat Bar 1
19 Selector Rod 1
20 Bracket 1 ¾” x 4 ¾” 4
21 U-shaped Bracket 2” x 7” 1
22 Lock Knob 1
23 Foam Tube 2
24 Backrest Board 1
25 Seat Pad 1
26 Arm Curl Pad 1
27 Large Foam Roll Ø 1 7/8” x Ø 8 5/8” 2
28 Foam Roll Ø 7/8” x Ø 7” 4
29 Weight Stack Cover Bracket 2
30 Double Floating Pulley Bracket 2
31 Rear Stabilizer End Cap 2
32 Weight Selector Pin 1
33 Chain 2
34 C-clip 4
35 Selector Stem 1
36 Weight Plate 14
37 Bushing Ø1” 8
38 Front Press Axle 3” 1
39 Butterfly Axle 2 5/8” 2
40 Leg Developer Axle 1
