HARDWARE PARTS LIST
17 ALLAN HEAD BOLT WITH BLUE DOT 2
18 FLAT WASHER 2
19 PLASTIC WASHER 2
20 FLAT WASHER 2
21 WAVY WASHER 2
36 SMALL FLAT WASHER 6
37 ADJUSTMENT KNOB 6
38 BOLT 6
64 NYLON LOCK NUT 2
65 FLAT WASHER 2
66 L & R PEDAL HINGE BOLT (L & R) 2
Parts described above are all the parts you need to assemble this machine. Before you start
to assemble, please check the hardware packing to make sure they are included. Please
note, some items of hardware my be pre assembled.
