5
Mareli Systems
1 Combustion chamber 13 Drain valve
2 Grill for burning 14 ermoregulator connection
3 Boiler body 15 Air valve
4 Exhaust gas connection 16 Hatch for cleaning
5 Water outlet 17
Flap with opening for smoke
extraction
6 Water inlet 18 Air vent valve
7 Upper door 19
Connections for the thermal
safety valve
8 Central door 20 Ash container
9 Lower door 21 Cleaning tool
10 Pellet burner mounting ange 22 Secondary air regulator
11 Boiler base 23
Fixing screw for secondary air
regulator
12 Insulation
LC
Greutate
(kg)
B (mm) H (mm) A (mm) C (mm) D (mm) E (mm) F (mm) G (mm) I (mm)
25 262 465 969 1294 160 300 864 1125 1235 Ø149
30 280 510 969 1294 160 300 1014 1140 1235 Ø149
35 301 560 969 1294 160 300 1014 1140 1235 Ø149
40 321 610 969 1294 160 300 1014 1115 1235 Ø179
50 350 610 1044 1294 160 300 1014 1115 1235 Ø179
