Margaritaville DM2000-033 - Page 5

-3- -4-
Frozen Concoction
Maker
™
Welcome
Cngrlis  r rch  t Mrgtvl®
Fro Cncoi Mkr™ – DM2000-033
To learn more about Margaritaville
®
products,
please visit us at www.margaritavillecargo.com.
PARTS LIST
1 Ice Reservoir Lid – Covers the Ice Reservoir.
2 Ice Reservoir – Holds the ice for making
frozen drinks.
3 Shaving Paddle – Moves ice across the
Shaving Blade.
4 Ice Hopper
4a Ice Hopper (ice deflector blade assembly) –
Feeds ice from reservoir to Shaving Blade.
5 Ice Shaving Blade – Shaves ice.
5a Ice Shaving Blade with deflector – Shaves ice.
6 Shaving Blade Assembly Nut – Holds Shaving
Blade in place.
6a U-Lock - Holds Shaving Blade in place.
7 Ice Chute – Directs ice from Ice Hopper into
Blending Jar.
8 Blending Base – Holds Blending Jar securely
in place.
9 Control Panel – Contains all necessary controls to
operate your unit.
10 On/Off Switch.
2
3
9
8
1
7
5
4
10
16
17
18
11
12
13
14
15
11 Jar Lid – Seals the blending jar.
12 Blending Jar – Maximum capacity of 36 oz.
13 Blending Blade Sealing Ring – Seals the blending jar and blending base.
14 Blending Blade – Creates forward action when blending drinks.
15 Jar Base – Designed with wide base for stability.
16 Ice Reservoir Release Button – Releases ice
reservoir from unit.
17 Ice Melt Reservoir – Contains melted ice excess.
18 Cord Storage Door – Covers power cord
storage area.
6 6a
5a
4a
