10
4. TECHINCAL DETAILS
AS 101S AS 121S
Acoustic Specs
Sound Pressure Maximum peak SPL 129 dB 131 dB
Frequency Response ±3dB 49 Hz - 120 Hz 47 Hz - 120 Hz
Frequency Range ±10dB 47 Hz - 130 Hz 45 Hz - 130 Hz
Dispersion Hor. x Vert. -
Loudspeakers Woofer LF 1 x 10” 1 x 12”
Coil Neodymium
Driver HF -
Horn -
Electrical Specs
Amp Type MOSFET Class A/B Class D
RMS Power 500W @ 4Ω 1200W @ 4Ω
Slew Rate 15V / μs
THD < 0.1%
Cooling Forced air
Protections Thermal
Limiter
DC Current
Short Circuit
DSP Dynamic Filtering (OPTIONAL)
Crossover Active 120 Hz (Hi-pass out) -
Input Sensitivity 500 mV balanced 800 mV balanced
Impedance 10 kΩ 22 kΩ
AC supply Type Switching
Voltage
100V; 120V; 230V; 240V 50/60Hz (Voltage is factory preset according to region of sale).
Markaudio
loudspeakers are manufactured to be sold and used in the country of purchase, and are factory preset to
that country’s voltage. Due to homologation issues, the voltage may not be changed.
NOTE: Check the voltage setting of your apparatus before plugging in the power cord.
Power absorption (medium) 350W 250W
Power absorption (max) 700W 1500W
Controls and connections
Controls 2x Hi-pass out level + Sub Level Sub Level
Phase 0° - 180°
Gnd In - Gnd Out lift
Indicators Power On
Clip
Connections 2x Line In (XLR)
2x Link Out (XLR)
2x Hi-pass Out (XLR)
Computer Connection (RJ45) OPTIONAL
AC In (VDE)
Construction features
Cabinet Material Multi-ply poplar
Finish Textured paint
Colour 8022 Brown
Protection grill Nickeled metal
Handles Quantity 1
Position Top
Hardware fitting adapter for M20 pole
Dimensions Width 362 mm / 14.25” 402 mm / 15.85”
Height 424 mm / 16.69” 464 mm / 18.27”
Depth 475 mm / 18.70” 567 mm / 22.32”
Weight 13.5 kg / 29.56 lbs 18.4 kg / 40.57 lbs
