Mark BEAM 201 - DMX Channel Mapping (cont.)

199-204 Gobo8,shaking slow to fast
205-211 Gobo9,shaking slow to fast
212-217 Gobo10,shaking slow to fast
218-223 Gobo11,shaking slow to fast
224-230 Gobo12,shaking slow to fast
231-236 Gobo13,shaking slow to fast
237-243 Gobo14,shaking slow to fast
244-249 Gobo15,shaking slow to fast
250-255 Gobo16,shaking slow to fast
5CH Prism 0-127 White
128-255 Prism
6CH Prism Rotate 0-20 Angle 0
21-41 Angle90
42-62 Angle180
63-83 Angle270
84-104 Angle360
105-126 Angle450
127 Angle540
128-190 Fast rotate to Slow rotate
191-192 stop
193-255 Slow rotate to fast rotate
7CH Empty 0-255
8CH Frost 0-255 0-100% Frost
9CH Focus 0-255 0-100% Focus
10CH X 0-255 540°
11CH X fine 0-255 1.8°
12CH Y 0-255 270°
13CH Y fine 0-255 1.8°
14CH Macro Function 0-11
12-24
25-37
38-50
51-62
63-255
15CH Reset 128 Reset
16CH Lamp 63 Off
178 On
17CH X.Y axis speed adjust 0-255 linearity control
18CH color speed adjust 0-255 linearity control
19CH Focus speed adjust 0-255 linearity control
20CH Patterns speed adjust 0-255 linearity control
BEAM 201 User Manual/Manual de uso Page 11
EN
