(Information) version)
POW(Power
reduction)
100%/80%/50%
LOAD(Load)
ST L(Setting load)
YES/NO
PR L(Program
load)
YES/NO
SEND(Send)
YES/NO
Instructions
:
When enter to the “*” position displayed on the LED, the light will automatically set as master and send data to
external. Other fixtures can receive this data and will synchronously running without manually set as slave. When
power cycle it will jump to the “*” position and running again.
6.1 DMX ADDRESS SETTING
1) Press the 【ENTER】
button in 【ADDR】
menu, then enter to the DMX address setting.
2) Press the
【UP/DOWN】button to select【1-512】numerical value.
3) Press the
【ENTER】button to escape and save.
6.2 STATIC SETTING
1) Press the
【ENTER】button in 【STAT】menu, then enter to the static setting.
2) Press the
【UP/DOWN】
button to select 【RED】,【GREEN】,【BLUE】and【PRST】.
3) Press the
【UP/DOWN】button to set up the
【0-255】numerical value.
4) Press the
【ENTER】button to escape and save.
6.3 COLOR CAST CALIBRATION SETTING
1) Press the
【ENTER】button in 【CAL】menu, then enter to the color cast calibration setting.
2) Press the
【UP/DOWN】button to select 【RED】,【GREEN】,【BLUE】
3) Press the
【UP/DOWN】button to set up the【0-255】numerical value.
4) On the【USE】interface, pressing
【YES】button means valid,
【NO】means invalid.
5) Press the
【ENTER】button to escape and save.
MBAR 381 IP - 8 - User Manual/Manual de Uso
