05
6. TECHNICAL SPECS
INPUT IMPEDANCE: 300 Kohm
GAIN: 0 ÷ +16dB
THRESHOLD: 30mVp ÷ 1,8Vp
RATIO: 1:1 ÷ 1:∞ (hard limiter)
ATTACK: 2 ÷ 50 ms
RELEASE: 100 ÷ 750 ms
OUTPUT IMPEDANCE: 100 ohm
POWER REQUIREMENTS DC INPUT: +12VDC 700mA
TUBE: 1X ECC81
DIMENSIONS: 170 x 145 x 60 mm
6.7” x 5.7” x 2.4”
WEIGHT: 750 g
1.66 lb
Mark your own preferred settings on the User Setting Chart below.
USER SETTING CHART MAKE UP YOUR OWN!
7. BLOCK DIAGRAM
